Arcs and Chords
Overview
Chords and their arcs rise and fall together: in the same circle, congruent chords cut off congruent arcs, and congruent chords sit the same distance from the center. The most useful fact in the lesson is what happens when a diameter or radius meets a chord at a right angle — it cuts the chord into two congruent segments and cuts its arc in half as well, which often sets up a right triangle.
Vocabulary
- Chord
- A segment whose two endpoints lie on the circle.
- Arc of a Chord
- The minor arc whose endpoints are the endpoints of the chord.
- Congruent Chords
- Chords of the same circle (or of congruent circles) that have the same length.
- Equidistant from the Center
- Two chords are equidistant from the center when the perpendicular distances from the center to the chords are equal. Distance from a point to a line is always measured along a perpendicular.
- Bisector
- A line, ray, or segment that divides a segment or an arc into two congruent parts.
Main Ideas
- In the same circle, or in congruent circles, two minor arcs are congruent if and only if their corresponding chords are congruent.
- In the same circle, or in congruent circles, two chords are congruent if and only if they are equidistant from the center.
- If a diameter or radius is perpendicular to a chord, then it bisects the chord and its arc.
- Because the perpendicular from the center bisects the chord, many chord problems become right-triangle problems: the hypotenuse is a radius, one leg is half the chord, and the other leg is the distance from the center.
Lesson Notes
Flip through the notes one page at a time using the buttons below.
Lesson Video
This lesson has 2 videos. Watch them in order.
Arcs and Chords
Arcs and Chords
Practice Problems
Want More Practice?
Download the practice worksheet for this lesson, work the problems, then check your work with the solutions.
