Polygons
Overview
This lesson names polygons by their number of sides and studies their angles. Drawing the diagonals from one vertex splits a convex polygon into (n − 2) triangles, which gives the interior angle sum S = (n − 2) · 180°. The exterior angles, one at each vertex, always add to 360°, and in a regular polygon — convex with all sides and all angles congruent — those totals divide evenly among the angles.
Vocabulary
- Polygon
- A multi-sided closed figure whose sides are segments that intersect only at their endpoints.
- Convex Polygon
- A polygon in which no line containing a side of the polygon also contains a point in the interior of the polygon. Simply: all vertices point out.
- Concave Polygon
- A polygon that is not convex. Simply: at least one vertex points in.
- Regular Polygon
- A convex polygon in which all sides and all angles are congruent.
- Exterior Angle of a Polygon
- The angle formed at a vertex between one side of the polygon and the extension of the adjacent side. An exterior angle and its adjacent interior angle are supplementary.
- n-gon
- A polygon with n sides. Special names: 3 triangle, 4 quadrilateral, 5 pentagon, 6 hexagon, 7 heptagon, 8 octagon, 9 nonagon, 10 decagon, 11 hendecagon, 12 dodecagon.
Main Ideas
- Polygons are classified by their number of sides, and the number of sides equals the number of interior angles and the number of exterior angles.
- The sum of the interior angles of a convex polygon is S = (n − 2) · 180°, because diagonals from one vertex form (n − 2) triangles.
- The sum of the exterior angles of a convex polygon, one angle at each vertex, is always 360°, no matter how many sides the polygon has.
- An interior angle and its adjacent exterior angle are supplementary — they add to 180°.
- In a regular polygon, each interior angle measures (n − 2) · 180° ÷ n, and each exterior angle measures 360° ÷ n.
- To find the number of sides, work the formulas backward: divide an interior sum by 180° and add 2, or divide 360° by the measure of one exterior angle of a regular polygon.
Lesson Notes
Flip through the notes one page at a time using the buttons below.
Lesson Video
Watch the lesson video.
Practice Problems
Want More Practice?
Download the practice worksheet for this lesson, work the problems, then check your work with the solutions.
