Angle Relationships
Overview
Pairs of angles have names based on how their measures combine and where they sit. Complementary angles total 90° and supplementary angles total 180°. Adjacent angles share a vertex and a side; vertical angles sit opposite each other where two lines intersect and are always congruent; a linear pair is both adjacent and supplementary. Perpendicular lines are the special case of intersecting lines that form right angles.
Vocabulary
- Complementary Angles
- Any two angles whose measures total 90°. Each angle is the complement of the other.
- Supplementary Angles
- Any two angles whose measures total 180°. Each angle is the supplement of the other.
- Adjacent Angles
- Two angles that share a vertex and one common side, with no interior points in common — they are next to each other with no gaps and no overlap.
- Vertical Angles
- Two non-adjacent angles formed by two intersecting lines, opposite each other at the intersection. Vertical angles are congruent.
- Linear Pair
- A pair of angles that are both adjacent and supplementary. The measures of a linear pair total 180°.
- Perpendicular Lines
- Lines that intersect to form right angles. A small square drawn at the vertex marks a right angle in a figure.
- Right Angle
- An angle whose measure is 90°.
Main Ideas
- Complementary means the measures add to 90°; supplementary means the measures add to 180°. The names describe the sum, not the positions — neither pair has to be adjacent.
- Vertical angles are congruent: set their measures equal. They are never adjacent.
- A linear pair is supplementary by definition, because the two angles together form a straight angle.
- Chain the relationships: find one angle from a pair, then use that result in the next relationship.
- After solving for x, substitute back and classify or report the measure asked for — algebra answers and angle measures are different things.
Lesson Notes
Flip through the notes one page at a time using the buttons below.
Lesson Video
Watch the lesson video.
Interactive Activity
Work with complementary, supplementary, vertical, and adjacent angles and the relationships between them.
Practice Problems
Want More Practice?
Download the practice worksheet for this lesson, work the problems, then check your work with the solutions.
